Replacing the power supply unit
40 BEETLE /M-III - Service manual
Assemble the device following the steps in reverse order.
NOTICE
The DMI files must be updated after a change in power supply units with respect to the serial number.
17.1 For a BEETLE /M-III with UPS
Shut down the system. Remove the cable cover and pull the power plug at the rear.
Remove the housing hood.
NOTICE
Observe the instructions regarding electrostatic discharge-sensitive assemblies (see chapter "Electrostatic dis-
charge-sensitive components").
Fold the hard disk holder upwards and set it aside.
To open the front panel, press the unlocking mechanism towards the front.
