Digi XBee Product Manual

Command reference tables
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 56
AT command options
EA
(v1.x80*)
Diagnostics ACK Failures. Reset/Read count of acknowledgment
failures. This parameter value increments when the
module expires its transmission retries without
receiving an ACK on a packet transmission. This count
saturates at its maximum value. Set the parameter to
“0” to reset count.
0 - 0xFFFF -
ED
(v1.x80*)
Diagnostics Energy Scan. Send ‘Energy Detect Scan’. ED
parameter determines the length of scan on each
channel. The maximal energy on each channel is
returned and each value is followed by a carriage
return. Values returned represent detected energy
levels in units of -dBm. Actual scan time on each
channel is measured as Time = [(2 ^ SD) * 15.36] ms.
Total scan time is this time multiplied by the number
of channels to be scanned.
0 - 6 -
* Firmware version in which the command was first introduced (firmware versions are numbered in
hexadecimal notation.)
Table 16: XBee / XBee-PRO commands - diagnostics
AT
Command
Command
Category Name and Description Parameter Range Default
Table 17: XBee / XBee-PRO commands - AT command options
AT
Command
Command
Category Name and Description Parameter Range Default
CT AT
Command
Mode
Options
Command Mode Timeout. Set/Read the period of
inactivity (no valid commands received) after which
the RF module automatically exits AT Command
Mode and returns to Idle Mode.
2 - 0xFFFF
[x 100 ms]
0x64
(100d)
CN AT
Command
Mode
Options
Exit Command Mode. Explicitly exit the module
from AT Command Mode.
--
AC
(v1.xA0*)
AT
Command
Mode
Options
Apply Changes. Explicitly apply changes to queued
parameter value(s) and re-initialize module.
--
GT AT
Command
Mode
Options
Guard Times. Set required period of silence before
and after the Command Sequence Characters of the
AT Command Mode Sequence (GT+ CC + GT). The
period of silence is used to prevent inadvertent
entrance into AT Command Mode.
2 - 0x0CE4
[x 1 ms]
0x3E8
(1000d)

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
