Digi XBee Product Manual

Worldwide acceptance
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 9
Worldwide acceptance
FCC Approval (USA) Refer to Agency certifications on page 98 for FCC requirements.
Systems that contain XBee / XBee-PRO RF Modules inherit Digi Certifications.
Industrial, Scientific and Medical (ISM) 2.4 GHz frequency band.
Manufactured under ISO 9001:2000 registered standards
XBee / XBee-PRO RF Modules are optimized for use in US, Canada, Australia, Israel and
Europe, contact Digi for a complete list of agency approvals.
Specifications
Advanced networking and security Easy to use
Retries and acknowledgments
Direct Sequence Spread Spectrum (DSSS)
Each direct sequence channel has over 65,000 unique
network addresses available
Source/destination addressing
Unicast and broadcast communications
Supports point-to-point, point-to-multipoint and peer-to-
peer topologies
Coordinator/End Device operations
Transparent and API operations
128-bit encryption
No configuration necessary for out-of box RF
communications
Free XCTU software (testing and configuration
software)
AT and API Command Modes for configuring
module parameters
Extensive command set
Small form factor
ADC and I/O line support
Analog-to-digital conversion, digital I/O
I/O line passing
Table 1: Specifications of the XBee / XBee-PRO OEM RF Module
Specification XBee XBee-PRO
Performance
Indoor/urban range Up to 100 ft (30 m) Up to 300 ft. (90 m), up to 200 ft
(60 m) International variant
Outdoor RF line-of-sight range Up to 300 ft (90 m) Up to 1 mile (1600 m), up to 2500 ft
(750 m) international variant
Transmit power output
(software selectable)
1mW (0 dBm) 63 mW (18dBm)*
10 mW (10 dBm) for International
variant
RF data rate 250,000 b/s 250,000 b/s
Serial interface data rate
(software selectable)
1200 b/s - 250 kb/s
(non-standard baud rates also
supported)
1200 bps - 250 kb/s
(non-standard baud rates also
supported)
Receiver sensitivity -92 dBm (1% packet error rate) -100 dBm (1% packet error rate)
Power requirements
Supply voltage 2.8 - 3.4 V 2.8 - 3.4 V

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
