XBee / XBee-PRO RF Modules 802.15.4 Product Manual 8
XBee
®
/ XBee-PRO
®
RF Modules
The XBee and XBee-PRO RF Modules were engineered to meet IEEE 802.15.4 standards and support
the unique needs of low-cost, low-power wireless sensor networks. The modules require minimal
power and provide reliable delivery of data between devices.
The modules operate within the ISM 2.4 GHz frequency band and are pin-for-pin compatible with
each other.
Key features of the XBee / XBee-PRO Modules
Long range data integrity Low power
XBee
• Indoor/urban: up to 100 ft (30 m)
• Outdoor line-of-sight: up to 300 ft (90 m)
• Transmit power: 1 mW (0 dBm)
• Receiver sensitivity: -92 dBm
XBee-PRO
• Indoor/Urbaun: up to 300 ft (90 m), 200' (60 m) for
international variant
• Outdoor line-of-sight: up to 1 mile (1600 m), 2500 ft
(750 m) for international variant
• Transmit power: 63 mW (18 dBm), 10 mW (10 dBm) for
international variant
• Receiver sensitivity: -100 dBm
• RF data rate: 250,000 b/s
XBee
• TX peak current: 45 mA (@3.3 V)
• RX current: 50 mA (@3.3 V)
• Power-down current: < 10 μA
XBee-PRO
• TX peak current: 250 mA,150 mA for
international variant
• TX peak current (RPSMA module only): 340 mA,
180 mA for international variant
• RX current: 55 mA (@3.3 V)
• Power-down current: < 10 μA

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
