Digital Dream DDCS V3.1 User Manual

Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual
Page -49
Y
-
ZERO
Y
-
ZERO
B: Zero All Axes:
After pressing to go to 2nd Mode,and pressing to go to the Go To Zero
mode,then we just press again to Zero All axes.Then there is no editing window come
up,system just do the action of all the axes “Zero”.
Shift
Figure 3-49 Zero All Axes
Figure 3-50 2ND Mode
3.3.5.3 Home
HOME
Z
-
ENTER
In Ready Mode,Press the key to enter into the 2ND Mode.
Press one time,the system turns to Home mode,as Picuture 3-50 and 3-51 show.
Shift
