INSTALLATION
Component Video Connections: Connect your component video sources to the COMPONENT 1/SCART,
COMPONENT 2 or RGB inputs as shown in Figure 3-9.
Y Pb P r
COMPONENT
1
-
SCAR T
R G B
Y Pb P r
COMPONENT
2
Y Pb P r
DTV Set-Top Box or
Other C o mp o nen t
(YPbPr) S o u r c e
Figure 3-9: Component Video Connections
