SPECIFICATIONS
7
L10 +?."@*)/".+F$*)&-&)'/&"(7!
!
!
!
Table 7-1 lists the Projector specifications.
Optics
Brightness
• 3500 lumens typical
• 3000 lumens minimum
Contrast
• 2000:1 typical
• 1500:1 minimum
Uniformity
• 85% typical
• 70% minimum
x
y
White
0.312
0.357
Red
0.634
0.358
Green
0.310
0.580 ( Meet REC709)
Blue
0.140
0.085
Color
Note: Color tolerance x,y = ± 0.03 for R, G; ± 0.15 for B
Resolution
TI” DMD, 0.95” X 1, 12 degree, DC2
Driver Technology
Dual 3021’s
Color Wheel
5-segment, RYGWB (2X)
Color Temperature
6500K ± 1500K
Lamp
1 x 260W lamp
Projection Lens
Short throw lens = 1.46 to 1.86:1 or Medium throw ratio = 1.85 to 2.5:1
Fixed lens = .73:1
Note: Values for 1080p w 0.95”
Projection Lens Image Offsets
• Vertical ± 120% V
• Horizontal ± 30% H
Image width range
8ft to 30 ft (see screen size table)
Prism/DMD Optics
DMD gasketed to prevent dust settling on panel - filter free optics
Electrical
I/O - Video Input
• DB15 pin RGB - primary input
• 2 x HDMI
• Component 1 - RCA
• Component 2 - BNC
• S-Video
57
