25 HYDRAULIC COMPONENTS
Dino 240 RXT, BOOM OPERATION, WITH OPTIONAL EQUIPMENT NO. 24010---
REF. NO. SPARE PART NO. PC ITEM
1 47.2081 1 DOUBLE PUMP, REXROTH
2 47.2855 1 SOLENOID VALVE
3 47.2871 1 MOUNTING PLATE
4 47.2850 5 SOLENOID VALVE
5 48.3449 1 ROTARY ADAPTOR 12-RING
6 47.2852 3 CHECK VALVE
7 47.2847 1 PROPO-VALVE L90
8 47.2846 1 PROPO-VALVE L90
9 47.2848 1 SOLENOID VALVE
10 3CB1234 4 CYLINDER (OUTRIGGER)
11 47.377 8 CHECK VALVE, OPENED BY PRESSURE
12 DL6.032 2 CYLINDER (ARTICULATED ARMS)
13 47.2766 3 LOAD REGULATION VALVE
14 DL6.031 1 CYLINDER (LIFTING OF BOOM)
15 47.2722 3 LOAD REGULATION VALVE
16 DL5.039 1 CYLINDER (TELESCOPE)
17 47.2273 1 HYDRAULIC MOTOR
18 47.1010 1 PRESSURE FILTER
19 47.196 1 RETURN FILTER
20 47.2317 1 POWER UNIT 12VDC/800W
21 47.2854 1 FLOW REGULATION VALVE
22 47.2961 1 SOLENOID VALVE
23 DL10.007 1 CYLINDER (MASTER)
24 DL10.005 1 CYLINDER (SLAVE)
25 47.2325 1 POWER UNIT 230V
26 47.294 1 CHECK VALVE
27 47.2920 1 CHECK VALVE
28 47.2921 1 CHECK VALVE
29 47.2917 1 PRESSURE RELIEF VALVE
30 47.2924 1 PRIORITY VALVE
31 47.2965 1 LOAD REGULATION VALVE
