Dinolift 240RXT - Electric Components List

DINO 240RXT
81
20.7 ELECTRIC COMPONENTS
REF. PART NR. DESCRIPTION
AD 48.3472 LEVELLING DISPLAY OF
CHASSIS
B1 48.2325 BATTERY
F1 48.3039 200A FUSE
F2-F5, F7,
F10-F12, F14
48.647 10A FUSE
F6 48.3038 16A FUSE
F8 48.3395 LEAD PROTECTION
F9 48.3037 3A FUSE
F13 48.3036 AUTOMATIC FUSE 4A
H1, H2, H3, 48.3469+48.3470 RED SIGNAL LAMP
H4 48.2204 GREEN LED -SIGNAL LAMP
H5, H6 48.3469+48.3471 YELLOW SIGNAL LAMP
J1 48.2085 CONTACT PLUG
K3,K9-K19,K22-
K24,K30-K39,
K41
48.2271 CHANGEOVER RELAY
K5, K8, K40 48.650 CHANGEOVER RELAY
K7 48.2277 CHANGEOVER RELAY
LS 48.3473 GRADIENT SENSOR
LX-AO, LX-A1 48.2326 JOYSTICK
M2 47.2317 POWER UNIT (RESERVE
POWER PLANT)
M3 48.2331 LINEAR ACTUATOR
M4 48.2332 LINEAR ACTUATOR
MDM 48.2327 DISPLAY
MS 48.2139 MAIN SWITCH
PL 48.3449 ROTARY ADAPTOR
(ELECTRIC PART)
PR 48.2145 CONTACT BOX (IN
PLATFORM)
Q1, Q2 48.3465 IGNITION LOCK
RK3 48.3508 LIMIT SWITCH
RK4 48.2068 + 48.2142 LIMIT SWITCH
RK5 48.2068 + 48.2142 LIMIT SWITCH
RK6 48.2068 + 48.2142 LIMIT SWITCH
RK7,RK15 48.2116 LIMIT SWITCH
RK8 48.2068 + 48.2142 LIMIT SWITCH
RK9,RK10 48.2170 TRAVEL STOP
RK11-RK14 48.3508 LIMIT SWITCH
RK16,RK17,RK
19
48.2270 INDUCTIVE SENSOR
RK18 48.2068 + 48.2142 LIMIT SWITCH
RPM 48.1981 ROTATION SPEED SENSOR
S1 48.2311 + 48.2313 EMERGENCY STOP -BUTTON
S4 48.2311 + 48.2313 EMERGENCY STOP -BUTTON
S11 48.2335 + 48.2312 PUSHBUTTON, YELLOW
S12 48.2309 + 48.2312 BUTTON, GREEN
S13 48.2335 + 48.2312 PUSHBUTTON, YELLOW
