DINO 240RXT
50
Extend the telescope until it stops (do not correct the position of the platform).
Measure the length of the protruding part of the telescope extension (stroke). The length shall be 1,800
mm ±50 mm.
Make sure that a red signal light on the platform is flashing and that the following text is on the display:
Outreach limit!
At the outreach limit!
If the protruding part is too long, adjust the limit switches and secure their position with a seal
(serviceman).
STROKE
