DINO 240RXT
52
Extend the telescope until it stops. (Do not correct the position of the platform).
Measure the length of the protruding part of the telescope extension (stroke). The length shall be 2100
mm ±50 mm.
If the protruding part is too long, adjust the limit switch and secure its position with a seal.
NOTE! Remember to resume the operation of the RK4 by removing the jumper lead.
STROKE
