Dinstar UC100 - FXO Trunk

UC100 User Manual
48
Copyright @ 2011-2015 Dinstar
Parameter
Explanation
Name
The name of the SIP trunk
IP Address
The IP address or domain name of the peer devices or servers
Port
The SIP listening port of the peer devices or servers; 5060 is the default
port
Outbound Proxy
If outbound proxy is used, enter the IP address or domain name of the
proxy server
Port
If outbound proxy is used, enter the listening port of the proxy server
Transport
Transport protocol: TCP or UDP
Register
Whether the SIP trunk is registered or not
Heartbeat
If heartbeat in on, heartbeat messages (options) will be sent to examine
the connection with servers. The default value is ‘Off’.
SIP Profile
The SIP profile of the SIP Trunk; make reference to Profile  SIP
Status
If it is enabled, it means the SIP Trunk is available; otherwise, the SIP
trunk is unavailable.
Note: If UC100 is regarded as a terminal and registered to SIP server, and you want to register the UC100,
you just need to register the corresponding SIP trunk.
4.8.2 FXO Trunk
FXO Trunk interconnects the PSTN with UC100. Calls from the PSTN can come into UC100 and calls can
go out from UC100 to search telephone numbers under the PSTN.
Different from the FXO ports of other gateways, the FXO port of UC100 only allows one-time dialing,
which means called numbers needs to be dialed directly for calls that go out from the FXO port.
