Operating Instructions RF-2000
46
This function sets output speed of spectrum data to the recorder or integrator. Enter
the desired set value with numeric key and press Enter.
Set value Output speed
1 1 nm/s
2 5 nm/s
3 10 nm/s
Please note:
When recording to a recorder or an integrator is performed
simultaneously with wavelength scanning, data is kept being
output to the recorder or integrator regardless of this setting.
SPC PLOT
(Output of spectrum)
EX(nm) EM(nm) Data
SPC PLOT
This function outputs spectrum data in the file set in SCAN FILE to a recorder or an
integrator.
Press Enter to start outputting to the recorder.
EVENT
(Setting of EVENT OUT terminal)
EX(nm) EM(nm) Data
EVENT __
This function sets ON (close) / OFF (open) of EVENT OUT terminal (relay contact)
located in the rear side of this equipment.
Enter the desired set value with numeric key and press Enter.
Set value EVENT OUT terminal
0 OFF (open)
1 ON (close)
EXT-S
(Function setting of EVENT OUT terminal)
EX(nm) EM(nm) Data
EXT-S __
This function specifies control mode for external instruments by EVENT OUT
terminal.
Enter the desired set value with numeric key and press Enter.
Set value Output speed
0 EVENT output is controlled by EVENT set
value.
1 Relay is turned ON for about one second
at a time program start.
2 Relay is turned ON at an occurrence of
error which cannot be reset.
3 Relay is turned ON during wavelength
scanning.
