Operating Instructions RF-2000
47
MONIT-TIME
(Setting of display of elapsed time of time program)
EX(nm) EM(nm) Data
MONIT-TIME __
This function displays the elapsed time from the time program start.
It is displayed on the TIME screen in AUX. FUNC.
Enter the desired set value with numeric key and press Enter.
Set value Function
0 Cancels display of elapsed time
1 Sets display of elapsed time
LAMP
(Setting of xenon lamp ON/OFF)
EX(nm) EM(nm) Data
LAMP __
This function controls ON/OFF of xenon lamp.
Set value Xenon lamp
0 OFF
1 ON
Please note:
When the xenon lamp is lit on, this instrument performs
initialization. After completion of initialization, all set values are
reset to the state before lit on lamp.
RATIO
(Setting of division correction to output signal)
EX(nm) EM(nm) Data
RATIO __
This instrument corrects the change of the fluorescence light energy caused by the
change of excitation light energy by dividing the monitored excitation light energy.
This function sets this correction.
Generally, this division correction is performed (Set value: 1).
Set value Functions
0 Outputs the fluorescence light energy.
1 Executes the division correction.
(Outputs the ratio of "fluorescence/
excitation")
2 Outputs the excitation light energy.
Please note:
When the xenon lamp is OFF (see item of LAMP), the value is
automatically set to "0" (outputs fluorescence light energy).
When the value is set to "1" (executes division correction) or "2"
(output the excitation light energy.) before the lamp is turned
OFF, the value is again set to "1" or "2" after the lamp is turned
ON.
