Chassis Assembly Specifications
Mechanical and Environmental
Dimensions (H x W x D) 8.7” x 17.6” x 15.8” (compatible with 19” EIA rack)
Weight
17.0 lbs. Includes 2 power supplies, 1 power supply
cover, no filler plates, no blades
Line Voltage 90–264 VAC, 47–64 Hz
Power Consumption MAX 1200W
Operating Temperature 0–50°C (32–122°F), non-condensing.
Blade Options
Satellite Receiver Blade 1 to 12 Blades
ATSC Receiver Blade 0 to 3 Blades
QAM 16 Blade 0 to 3 Blades
QAM 48 Blade 0 to 2 Blades
QAM 96 Blade 0 to 2 Blades
NTSC Analog Blade 0 to 3 Blades
Satellite Inputs (from LNB)
Number of Inputs 4, labeled Sat 1 thru Sat 4
Connector F, female
Impedance 75 ohms
Input Frequency L-Band, 950 – 2150 MHz
Input Power -25 to -65 dBm, aggregate
Return Loss > 15dB
Satellite Input LED Indicators
Number of LEDs 4, associated with each of 4 satellite inputs
Green Signal power is detected on LNB
Amber High signal on LNB
Red Low or no signal detected
Network Interfaces
Number of Inputs 4, labeled Data 1 through Data 4
Connections RJ-45, GbE, Full Duplex, Auto-Negotiate
Addressing Multicast
Transport Protocol UDP/IP
Transport Format SPTS
IP Management HTTP, TR-069
Local User Interface Web Browser
