Satellite Receiver Blade
Dimensions (H x W x D) 7.5 x 0.9 x 14.5
Power Consumption 30W (Typical)
Satellite Channels 8 transponders and/or 8 programs
Modulation Rates DVB-S: Symbol Rates 1 to 45 MSps
Interleave 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2: Symbol Rates 5 to 33 MSps
QPSK Interleave 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK Interleave 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
Turbo FEC: Symbol Rates 2 to 30 MSps
QPSK Interleave 1/2, 2/3, 3/4, 5/6, 7/8
8PSK Interleave 2/3, 3/4, 4/5, 5/6, 8/9
Acquisition Range ± 5 MHz
Satellite Receiver Blade with Transcoder Module
Dimensions (H x W x D) 7.5 x 0.9 x 14.5
Power Consumption 60W (Typical)
Satellite Channels 8 transponders and/or 8 programs
Modulation Rates DVB-S: Symbol Rates 1 to 45 MSps
Interleave 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2: Symbol Rates 5 to 33 MSps
QPSK Interleave 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK Interleave 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
Turbo FEC: Symbol Rates 2 to 30 MSps
QPSK Interleave 1/2, 2/3, 3/4, 5/6, 7/8
8PSK Interleave 2/3, 3/4, 4/5, 5/6, 8/9
Acquisition Range ± 5 MHz
Conversions Supported MPEG-4 (Native) to MPEG-2 either HD or SD with no format conversion
ATSC Receiver Blade
Dimensions (H x W x D) 7.5 x 0.9 x 13.5
Power Consumption 20W (Typical)
Connector F-Female
ATSC Channels 8 carriers and/or 8 programs
Frequency Range 42–1002 MHz
Input Level per Carrier -35 to +44 dBmV
Return Loss >15 dB
Impedance 75 ohms
Optional Modules Transcoder
