Dish Network Smartbox - QAM 16 Blade; QAM16 Blade; QAM 48 Blade; QAM48 Blade

69
QAM 16 Blade
Dimensions (H x W x D) 7.5 x 0.9 x 13.5
Power Consumption 25W (typical)
Connector F-Female
Output Frequency 54–1002 MHz
Channel Bandwidth 16 channels, 6 MHz per channel
Modulation ITU-T J.83B Annex B (256QAM), Inverse
QAM Symbol Rate 5.360537 MSps
Interleaving 128/1 Annex B
Channel Plans EIA, HRC, IRC, Manual
Output Frequency
Accuracy
125 Hz
Output Level 45 dBmV eective precombined output power
Output Attenuation 0 to 10 dB (0.5 dB step)
Output Level Flatness (54 to 864 MHz) ±1 dB
(864 to 1002 MHz) ±2 dB
Spurious > 60 dBc (in 4MHz)
Output Impedance 75 ohms
Output Return Loss >11 dB
QAM 48 Blade
Dimensions (H x W x D) 7.5 x 0.9 x 13.5
Power Consumption 50W (typical)
Connector F-Female
Output Frequency 54 to 1002 MHz
Channel Bandwidth 48 channels, 6 MHz per channel
Modulation ITU-T J.83B Annex B (256QAM), Inverse
QAM Symbol Rate 5.360537 MSps
Interleaving 128/1 Annex B
Channel Plans EIA, HRC, IRC, Manual
Output Frequency
Accuracy
125 Hz
Output Level 45 dBmV eective precombined output power
Output Attenuation 0 to 10 dB (0.5 dB step)
Output Level Flatness (54 to 864 MHz) ±1 dB
(864 to 1002 MHz) ±2 dB
Spurious > 60 dBc (in 4MHz)
Output Impedance 75 ohms
Output Return Loss >11 dB
