QAM 96 Blade
Dimensions (H x W x D) 7.5 x 0.9 x 13.5
Power Consumption 40W (typical)
Connector F-Female
Output Frequency 54 to 1002 MHz, 768 MHz channel range maximum
Channel Bandwidth 3.83, 5.48, 5.56, 5.67, 5.75, 6.43, 6.88, 7.71
Modulation ITU-T J.83B Annex A (64, 128, 256 QAM)
QAM Symbol Rate 3.33, 4.76, 4.84, 4.93, 5.00, 5.59, 5.98, 6.70 MSps
Interleaving 128/1 Annex B
Channel Plans EIA, HRC, IRC, Manual
Output Frequency
Accuracy
125 Hz
Output Level 45 dBmV eective precombined output power
Output Attenuation 0 to 10 dB (0.5 dB step)
Output Level Flatness (54 to 864 MHz) ±1 dB
(864 to 1002 MHz) ±2 dB
Spurious > 60 dBc (in 4MHz)
Output Impedance 75 ohms
Output Return Loss >11 dB
NTSC 24 Blade
Dimensions (H x W x D) 7.5 x 0.9 x 13.5
Power Consumption 50W (typical)
Connector F-Female
Maximum Number of NTSC
Channels
24 NTSC RF with mono audio
Frequency Range 120 to 552 MHz
Band Plan STD, IRC
Output Level 24 NTSC Channels 45 dBmV (min per channel)
Output Adjust Range 10 dB
Attenuation Steps Increment 0.5 dB
Output Impedance 75 ohms
Output Return Loss In-Band -11 dB 120 to 552 MHz
RF Flatness Response ±1 dB 120 to 552 MHz
Carrier Frequency Stability 5 kHz Std channel
Audio/Video Carrier Ratio 15 ±2 dB
