JT40/JT40 All Terrain Operator’s Manual Controls - 33
Left Control Console
6. Pipe shuttle switch To move toward pipe box,
press top.
To move toward spindle,
press bottom.
To stop shuttles, release.
7. Pipe lift switch To raise, press top.
To lower, press bottom.
To stop, release.
8. Wrench control To clamp rear wrench, push
forward.
To unclamp rear wrench, pull
back.
To clamp front wrench, move
to right.
To unclamp front wrench,
move to left.
9. Pipe lubricator switch To apply joint compound,
press.
Applies joint compound to threads at
wrenches.
Item Description Notes
