JT40/JT40 All Terrain Operator’s Manual Controls - 39
Left Control Console
10. Rotary operation
control
Turn knob to control the
following functions:
Press and turn knob to allow
finer control of the following
functions.
Manual inner spindle speed
control:
To increase manual inner
spindle speed, turn clockwise.
To decrease manual inner
spindle speed, turn
counterclockwise.
Automated inner spindle
speed control:
To increase rotation speed,
turn clockwise.
To decrease rotation speed,
turn counterclockwise.
Fluid flow control
To increase flow, turn
clockwise.
To decrease flow, turn
counterclockwise.
Carve window control:
To increase carve window
range, turn clockwise.
To decrease carve window
range, turn counterclockwise
See “Manual inner spindle control” on
page 36.
See “Automated inner spindle control”
on page 36.
See “Drilling fluid pump switch” on
page 45.
See “AutoCarve control” on page 37.
Item Description Notes
