DITEC EL500E - Page 25

25
IP2358EN
4 1 > FORCE CONTROL SETTINGS
41:
0 0
00
Default value. Not to be modified
23 > EXTRA SAFETY EDGE
32 > AUTO CLOSE SELECT
31 > PHOTOCELLS SETTINGS
29 > DISENGAGEMENT
23:
0 0
00
23:02
23:01
23:03
No extra safety edge list
Extra safety edge list works parallel with primary safety edge list
Extra safety list stops door in opening direction
Extra safety list stops door and reverse a little in opening direction
32:
0 0
00
>00
No auto closing
Seconds 1 – 990 (after 99 the changing will be in x10 of seconds and the value is flashing quickly)
31:
0 0
00
31:02
31:01
31:03
No Photo safety connected
Photo 1 connected
Photo 2 connected
Photo 1 and 2 connected
29:
0 0
00
29:0 2
29:0 1
29:0 4
29:0 3
No wire tighten function
Wire tighten 5mS
Wire tighten 10mS
Wire tighten 20mS
Wire tighten 30mS
34:
0 0
00
34:0 2
34:0 1
34:0 4
34:0 3
No forced closing
Forced closing after 2min (even though photocell has not been activated)
Forced closing after 5min (even though photocell has not been activated)
Forced closing after 10min (even though photocell has not been activated)
Forced closing after 20min (even though photocell has not been activated)
33 > CAR WASH FUNCTION
34 > “FORCED” CLOSING
33:
0 0
00
>00
No car wash function
Photocell active time in 0,1 sec. Units (e. g. 15 = 1,5sec.) - (Adjustable 1 – 30 units – 0,1 sec. to 3,0sec.)
35 > OPTIONAL RADIO MODULE NRGZENX1 - “GO FUNCTION”
35:
0 0
00
35:02
35:03
35:0 1
Normal go function (Closing is only possible from open limit)
Special go function (stop command possible in opening direction)
Go function with open function only
Operation’s logic step-by-step
36 > TEMPORARY DISABLING OF AUTOMATIC CLOSING
36:00
36:
0 1
01
Function OFF
Function ON
22 > AFTER RUN
21:
0 0
00
>00
No after run
After run active – after run time 0.01 – 0.50 sec.
pag. 18
pag. 21
pag. 22
pag. 19
pag. 19
pag. 28
Function that allows the disengagement on stop during losing.
Configurable only when “car wash” is active.
