DITEC EL500E - Page 26

26
IP2358EN
59 > SERVICE COUNT ALERT
59:
0 0
00
59:01
Display shows E:04
Switch to hold-to-run control and display shows E:04
51 > RUN TIME CONTROL
58 > SERVICE COUNTER SETUP
51:00
51:
0 2
02
51:01
51:04
51:03
No run time control
Run time 20 sec
Run time 40 sec
Automatic learning
Run time 60 sec
58:
0 0
00
58:0 2
58:0 1
58:0 4
58:0 3
No Service countdown
15 open cycles before service (for test only)
5000 open cycles before service
10000 open cycles before service
20000 open cycles before service
52 > REVERSE TIME OF SAFETY EDGE
Reverse time of safety edge in 1/100 seconds. 0.00 – 0.99 sec. (default 0,004 sec.)
53 > REVERSE TIME OF PHOTOCELL
Reverse time of Photo in 1/100 seconds. 0.05 – 0.99 sec. (default 0,30 sec.)
81 > DELAY TIME INDICATION OF MISSING ENCODER POSITION
81:00
81:02
81:01
81:
0 3
03
1 second
2 second
4 second
4 second with automatic reset
84 > SPECIAL OPEN FUNCTION
84:
0 0
00
84:01
Normal open function
Special open function (Open signal with high priority. The door will always open on a continuously open
signal, even after a stop command)
88 > OPTION RELAY (K3)
88:
0 0
00
88:02
88:01
88:03
Relay active when door is running
Relay active when the door is closed
Relay active when the door is open
Relay used for electric lock
pag. 18
pag. 23
