dji RONIN 4D User Manual

DJI Ronin 4D User Manual
13
©
2022 DJI All Rights Reserved.
Ronin 4D-6K also supports the DJI PROSSD Mount and the DJI PROSSD 1TB but they are not
included in the package. Attach the DJI PROSSD Mount before attaching the DJI PROSSD 1TB.
1. Open the card compartment cover
1
, press the clip
2
inside, and remove the cover.
2. Locate the arrow on the CFexpress card plug and insert it into the card slot of Ronin 4D based on
the direction of the arrow.
1
2
1
2
Attaching CFexpress2.0 Type-B Card: Open the card compartment cover and insert the card.
2
1
2
1
3. Remove the two M2×5 screws
1
on Ronin 4D, align the PROSSD mount with the screw holes, and
attach using the two M2×22 screws
2
included with the PROSSD mount.

dji RONIN 4D Specifications

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
