DJI Ronin 4D User Manual
67
©
2022 DJI All Rights Reserved.
Focus Control
Ronin 4D provides Manual Focus, Auto Focus, and Automated Manual Focus. Auto Focus and
Automated Manual Focus requires the LiDAR range finder. Controlling the focus of the manual lens
requires the X9 Focus Motor and lens calibration.
Manual Focus
When using a third-party lens, manual focus can be used after calibrating the lens via the dial of the right
hand grip or the main body with the MF Readings on the main monitor screen. Press the Focus Peak
button on the right hand grip or the main monitor to enable or disable focus assistant.
With the LiDAR range nder mounted, the LiDAR sensor scans forward and displays objects on a depth
map. Subjects can be quickly located using the MF readings.
Auto Focus
Auto focus can be used via the AF/MF button on the screen or AF button on the right hand grip when
using a third-party lens that has been calibrated.
Press Focus button on the right hand grip or tap AF on the main monitor to enable Autofocus.
Automated Manual Focus
Go to the menu, select Lens, and AMF. During AMF, Ronin 4D will focus automatically and user can use
the dial or DJI 3-Channel Follow Focus to manually adjust focus at anytime.
PEAK
AF
A001C0001
A001C0001
30
60’
5‘6
15
20
12
8
7
6’
5
4‘6
4
3‘6
3
2‘9
2‘6
10
ft
35mm
08:02:16:06
TC
8K
5600K
W
B
ND
2(0.3)
F2.8
IRIS
800
EI
1/80
SS
29.97
FPS
AF
Track
FPV
Med
Z-Axis
Follow
1
1
2
2
193:32
100
AF
