Auto Tune
Make sure to autotune Ronin 4D before using to ensure optimal performance. Tap HOME on the high-
bright main monitor and select Stabilizer, Gimbal Calibration, and Auto Tune.
Make sure the three axes of the gimbal are unlocked and the GIMBAL MODE is toggled to FOLLOW
or LOCK before auto tune.
Make sure Ronin 4D is placed on a at and steady surface before autotuning. It is normal for the
gimbal to vibrate and emit sounds during autotune.
Ronin 4D must be autotuned each time the camera lens or the payload is changed.
The gimbal balance icon on the high-bright main monitor is white if the balance is suitable for
shooting. If the icon is orange , it is recommended to rebalance the gimbal for optimal performance.
The gimbal must be rebalanced if the icon is red . Tap the gimbal balance icon and balance the gimbal
according to the tips on the screen. The camera is front-heavy if the left side of the bar below the pan or
tilt axis is red and the axis needs to be adjusted backward. The camera is back-heavy if the right side of
the bar below the pan or tilt axis is red and the axis needs to be adjusted forward.

dji RONIN 4D Specifications

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
