dji RONIN 4D User Manual

DJI Ronin 4D User Manual
40
©
2022 DJI All Rights Reserved.
Menu and Functions
Press the HOME button to enter the menu.
Recording
The recording menu consists of the three sub menus of Video, Audio, and Settings.
Video
Image Area
The image area can be set to Full Frame or Super 35. The sensor size is shown below.
8K: Full Frame 36×19 mm; Super 35 24.5×13 mm
6K: Full Frame 35.7×18.8 mm; Super 35 24.3×12.8 mm
X9-6K
Super 35
Full Frame
17 : 9
6K/4K/2K
2.39 : 1
6K/4K
17 : 9
4K
2.39 : 1
4K
X9-8K
Super 35
Full Frame
17 : 9
8K/4K
2.39 : 1
8K
17 : 9
5.5K/4K

dji RONIN 4D Specifications

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
