DJI Ronin 4D User Manual

Inserting the Storage Media

Ronin 4D supports the DJI PROSSD 1TB when used with the DJI PROSSD Mount, CFexpress2.0

Type-B cards, and USB 3.1 Type-C SSDs*. The DJI PROSSD 1TB supports internal recording of the

highest format and the footage can be read in the computer directly through the provided USB-C to

USB-C cable. No card reader is required.

ClickClick

Attaching the Intelligent Battery

Align the Intelligent Battery with the battery compartment and push the battery down until there is a

clicking sound.

* Visit https://www.dji.com/ronin-4d/faq to learn more about supported CFexpress 2.0 Type-B cards and USB

3.1 Type-C SSDs. Make sure to use the original cable of the USB-C SSD for optimal performance.

Attaching the DJI PROSSD Mount and the DJI PROSSD 1TB: The DJI PROSSD Mount is mounted

on Ronin 4D-8K by default. Attach the DJI PROSSD 1TB to the DJI PROSSD Mount.

Other manuals for dji RONIN 4D

Questions and Answers:

Need help?

Do you have a question about the dji RONIN 4D and is the answer not in the manual?

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
