DJI Ronin 4D User Manual
41
©
2022 DJI All Rights Reserved.
Recording Codec/Resolution/Sensor FPS
Refer to the Frame Rate Setting table for more information.
Storage
Storage can be selected when the DJI PROSSD 1TB or CFexpress card and USB-C SSD is used.
Rec LUT
Tap to choose from Rec.709, D-Log, HLG, or LOOK. LOOK is the custom LUT from the user. Refer to
LOOK section for more information. The Rec LUT will apply to the recorded footage. The monitor LUT
and recording LUT can be set independently. The monitor LUT will not aect the recorded footage.
Select Display, Monitor, and then Monitor LUT to set the Monitor LUT.
Camera Index
Tap to set the camera index, which can be set from A to Z. The camera index will be included in the
footage name and the camera name when using Broadcast mode.
Next Reel Count
Tap to set the reel index of the next storage media. The setting range is 1 to 999 and the reel index will
be included in the name of the footage.
In the following scenarios, the camera will recognize the storage media as a new storage. The current
reel index will be used in the next reel count when the recording begins and continue from the previous
reel count.
1. The selected storage did not record anything in this camera using this camera index.
2. The selected storage is empty after formatting.
Clip
Displays the last recorded clip number with the camera using the current camera index. The clip number
range is 0000 to 9999 and cannot be set.
The folder name of the footage consists of the reel index, clip number, and the sux of Ronin 4D serial
number. The lename of the footage consists of the camera index, reel index, clip number, date, and
the sux of Ronin 4D serial number. The lename B021C0001_ BD13 is used as an example to explain
below.
If the recording exceeds 3 hours, the footage will be stored as a new le and the name of the le will be
the following clip number.
B021C0001...
B021C0002...
B021C0001_211212_ BD13.MOV
Ronin 4D SN
Camera Index
Reel Index
Clip Number
Year
Date
Month
