DJI Ronin 4D User Manual
30
©
2022 DJI All Rights Reserved.
1. Dial
Turn to adjust focus, ND, EI, or aperture and to scroll through options on the high-bright main
monitor. Turn the dial to control focus by default and press the mode button to scroll through the
options. The dial uses continuous damping when controlling aperture and contact damping when
controlling EI or ND.
2. Record Button
Press once to start or stop recording. The button glows solid red during recording and is o when
not recording.
3. Hand Grip Angle Adjustment Lever
Press and hold the lever to adjust the angle of the hand grip. The hand grip will lock once the lever is
released. Do not adjust the left and right hand grips simultaneously.
4. Hand Grip Lock Lever
Used to lock the hand grip.
5. Focus Peak Button
Press once to enable or disable the focus assist display.
6. Mode Button
Press once to switch the function of the dial from controlling focus, ND, EI, or aperture. Press and
hold to switch to controlling focus.
7. Trigger
Press twice to enable or disable the Z-axis.
When Z-axis is enabled and in follow mode, press and hold to enter lock mode.
8. Focus Button
Press once to switch between manual focus and auto focus.
9. Safety Lock
Release the safety lock before detaching the hand grip.
Right Hand Grip
1
3
4
2
7
8
9
6
5
