DJI Ronin 4D User Manual
35
©
2022 DJI All Rights Reserved.
3. Iris
Displays the iris value. “F- -” will be displayed when the lens is not recognized. Tap the icon or
the button above to access settings. The EV can be adjusted manually after enabling Auto. The
setting range is -3 to +3. Metering will be based on the center area and the iris will be adjusted
automatically. The iris will be adjusted prior to shutter speed when both the aperture and shutter
speed or angle are set to auto.
4. Shutter Speed/Angle
Tap the icon or press the button above to adjust shutter speed or shutter angle. The EV can be
adjusted manually after enabling Auto. The setting range is -3 to +3. Press and hold the icon or
button for advanced settings. Tap Add to add custom shutter speed or angle to the list. The range
of the shutter speed is 1/30 s to 1/8000 s and the range of the shutter angle is 11.2° to 358°. Tap
Shutter Unit to select Angle or Speed. Tap Delete to delete the shutter speed or angle from the list.
The current shutter speed or angle cannot be deleted.
The EV value will be adjusted automatically when switching between the shutter speed and angle.
The iris will be adjusted prior to shutter speed when both the iris and shutter speed or angle are set
to auto.
5. Frame Rate
Displays the frame rate. Tap the icon or press the button above to set the frame rate. Once Slow is
enabled, the project frame rate and sensor frame rate can be set separately. The camera will record
in slow motion and the audio cannot be recorded when the sensor frame rate is double or more of
the project frame rate.
Note that some frame rate changes will cause the image area and recording codec to change. The
max project frame rate is 60fps. Slow must be enabled to shoot at a frame rate higher than 60fps.
Refer to the Frame Rate Setting table below to learn more.
√
17:9
√
2.39:1
X9-8K Sensor FPS
Codec Resolution Image Area 23.976 24 25 29.97 30 48 50 59.94 60 72 75 96 100 120
ProRes RAW 8K FF √ √ √ √ √ √ √ √ √ √ √
5.5K S35 √ √ √ √ √ √ √ √ √
ProRes 422HQ 8K FF √ √ √ √ √
4K FF √ √ √ √ √ √ √ √ √
S35 √ √ √ √ √ √ √ √ √
H.264 4K FF √ √ √ √ √ √ √ √ √
S35 √ √ √ √ √ √ √ √ √
X9-6K Sensor FPS
ProRes RAW 6K FF √ √ √ √ √ √ √ √ √
4K S35 √ √ √ √ √ √ √ √ √ √ √ √ √
ProRes 422HQ 6K FF √ √ √ √ √ √ √ √ √
4K FF √ √ √ √ √ √ √ √ √
S35 √ √ √ √ √ √ √ √ √ √ √ √ √
2K FF √ √ √ √ √ √ √ √ √ √ √ √ √
S35 √ √ √ √ √ √ √ √ √ √ √
H.264 4K FF √ √ √ √ √ √ √ √ √
S35 √ √ √ √ √ √ √ √ √ √ √ √ √
2K FF √ √ √ √ √ √ √ √ √ √ √ √ √
S35 √ √ √ √ √ √ √ √ √ √ √
6. MF Readings
The MF readings will be displayed when using a DL lens or after other lens has been calibrated. The
MF readings will move up and down along with the focal position. The yellow triangle indicates the
current focal position. In MF (Manual Focus) or AMF (Automated Manual Focus) mode, turn the multi
dial on the main body or the dial of the right hand grip to control the focus manually. The minimum
focus distance of Ronin 4D is 1 foot (approx. 0.3 m). Select Lens, Focus, and Unit in the high-bright
