dji RONIN 4D User Manual

DJI Ronin 4D User Manual
6
©
2022 DJI All Rights Reserved.
Ronin 4D Diagram
1. Gimbal and Camera
2. Z-Axis
3. Base Plate
4. Left Hand Grip
5. Top Handle
6. LiDAR Range Finder
7. High-Bright Main Monitor
8. TB50 Intelligent Battery and Battery
Compartment
9. Main Body
10. Right Hand Grip
1
6
2
3
9
4
10
5
7
8

dji RONIN 4D Specifications

General

Camera Sensor	Full-Frame CMOS
Dynamic Range	14+ stops
Battery	TB50 Intelligent Battery
Sensor Size	36 x 24 mm
Video Resolution	6K (4096 x 2160)
Lens Mount	DL mount, with E-mount compatibility via adapter
Stabilization	4-axis stabilization
Recording Formats	Apple ProRes 422 HQ, H.264
Frame Rates	Up to 6K/60fps, 4K/120fps
Storage	CFexpress Type-B
Audio Input	3.5mm
Display	5.5-inch touchscreen
Battery Life	Approx. 2.5 hours
Internal ND Filters	Built-in ND filters (ND 2 to ND 512)
Weight	Approx. 4.67 kg (without lens)
