FlexxPump 125 (24V)
User Manual
26
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
Display in LCD Meaning Chapter
dark Power supply not connected 6.3.3
OFF FlexxPump 125 is switched o 6.3.3
On FlexxPump 125 is ready for operation; FlexxPump 125
dispenses lubricant in accordance to the operation
mode and the set values
6.3.3
PUL FlexxPump 125 is ready for operation in the Pulse-Con-
trol-Mode PUL and is waiting for control signal from
external control (PLC)
8
PUL (ashing) FlexxPump 125 receives a control signal from the exter-
nal controller (PLC).
8
--- Received control signal longer than 15 sec. 8.2
Errors
E1 Error E1 (Empty cartridge / no cartridge detected) 6.4
E2 Error E2 (Overload) 6.4
E3 Error E3 (Undervoltage) 6.4
E4 Error E4 (fatal error) 6.4
Sub-Menu
INF
INF-Menu 6.3.4
6.3.5
6.3.6
n01 Firmware version of the FlexxPump 125
h06 Currently set value of the pause time h
c01 Currently set value of the number of cycles c
6 Currenty set value of the emptying time Et
PUL Currently set operation mode Pulse-Control-Mode
125 Currently set cartridge size
SET SET-Menu 6.3.7
-h- Operating mode Hour-Mode
Et Operating mode Empty-Time-Mode
PUL Operating mode Pulse-Control-Mode
125/250 Adjustable value of the cartridge size
RUN
RUN-Menu 6.3.8
01...50 During the manually triggered active RUN command
("Quick-Check"/special donation), the LCD displays the
approximate back pressure in bar. In addition, the green
LED lights up.
