DLS FlexxPump 125 - Page 27

revision: 0
FlexxPump 125 (24V)
User Manual
27
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
PRO PRO-Menu 6.3.9
6.3.10
6.3.11
h1...240 Adjustable setting of the pause time h
c1...10 Adjustbale setting of the number of strokes c
01...24 Adjustabe setting of the emptying time Et
PUL Currently set operating mode Pulse-Control-Mode, no
changeable variable
FIL FIL-Menu 6.3.12
01...50 During the manually triggered active FIL command, the
LCD displays the approximate back pressure in bar. In
addition, the green LED lights up.
Clr If the process is aborted during the FIL command, Clr
appears rst.
Additional character on the LCD
Displayed when the cartridge is empty and the cartridge
and battery need to be replaced.
9.2
MAX After each cycle the maximum back pressure is display-
ed in bar.
