DMC SuperSigma2 QRM User Manual

SuperSigma2 QRM PMS – V01.02.02 17-1-2020 Page 23 (58) ©2019 DMC GmbH Herten Germany
9.4.1 Status tables
M2-3 BDI States table
BDI States
Description
0
Initializing
1
OK
2
BDI is getting low Warning (WO)
3
BDI is too low Cut out (CO)
M2-6 Drive and brake status table
Status
Description
NC
No Configuration
N
Neutral, not pulsing
FD
Forward drive
RD
Reverse drive
DB
Direction braking
NB
Neutral braking
FB
Foot braking
FB
Hill hold
HF
Forward restraint hill hold
HR
Reverse restraint hill hold
Shared Line Contactor Status table
Status
Description
ST
Starting up
RC
Ready to close Line Contactor
CS
Is closing line contactor
PS
Start pulsing
KF
Key fault is found
NK
Not known
M2-7 Speed limits table
Limit
Description
MS
Motor speed
SM
Speed limit forward or reverse
S1
Speed 1 limit
S2
Speed 2 limit
S3
Speed 3 limit
S4
Speed 4 limit
S5
Speed 5 limit
S6
Speed 6 limit
SI
Inching
SB
BDI speed limit
SH
Hand brake speed limit
SV
Control Via CAN HMI limit
CS
Controller over temperature limit
SS
Steering Pot Speed Limit
M2-8 Torque limits table
Limit
Description
CT
Controller temperature
MT
Motor temperature
PT
Performance table current limit
TC
Timed Current Limit
T1
I
2
t current limit step 1
T2
I
2
t current limit step 2
T3
I
2
t current limit step 3
HV
High Voltage limit
LV
Low Voltage limit
HB
Hand brake limit
S1
Advanced mode speed 1 active
S2
Advanced mode speed 2 active
BM
Battery current limit maximum
BR
Battery current limit regen
M2-9 Motor limits table
Limit
Description
TL
Torque Limit
SL
Speed Limit
TH
Not able to hold torque
SH
Not able to hold speed
FH
Not able to hold flux
IH
Not able to hold flux current
CH
Not able to hold circle limitation
HL
Not able to hold hexagon limit
OL
Circle limitation
