4.3 Mechanical

Details: See mechanical drawings.

Enclosure: Aluminium heat sink with ABS plastic cover.

Power connections: Vertical Copper studs.

Hexagonal: Fixing torque 9.5Nm (Slot screws are recommended!)

Slot screw: Recommended, fixing torque 9.5Nm (Brass)

Bolt length: Max 20mm incl. washer and spring washer

Weight: Size1: 3.25kg; Size2: 4.1kg; Size3: 4.9kg; Size4: 6.2kg;

Always use a torque wrench when fixing the power terminals.

Exceeding the maximum specified torque can cause serious damage to the controller and warranty

might be void.

Too long bolts damage the controller.
