SuperSigma2 QRM PMS V01.02.02 17-1-2020 Page 55 (58) ©2019 DMC GmbH Herten Germany
11.5 iGauge Display Connection diagram
The iGauge is a 52mm diameter indicator.
It is capable of indicating lead acid battery discharge state, hours counter and the main SuperSigma2 fault messages.
11.6 Power Wiring
When an emergency battery disconnect switch is fitted, the key switch must be fed through an
auxiliary switch to prevent over voltage damage due to disconnect during regen.
Connector B (8-Way)
Tx
C AN L
1 N/C
12V Supply ( +)
7
Rx
5
2
C AN H
0V S upply ( -)
4
Tx - Flash
4
6
+12V Flash3
+12V
iGauge Connector
8
2
0V
R x - Flash
3
1
