2 SUPERSIGMA2 VARIANTS
Model Nr.
Power
AC Traction
PAC960T4-**
60-96V 600Arms
PAC945T3-**
60-96V 450Arms
PAC927T2-**
60-96V 270Arms
PAC914T1-**
60-96V 140Arms
PAC460T3-**
24-48V 600Arms
PAC445T2-**
24-48V 450Arms
PAC425T1-**
24-48V 250Arms
AC Pump
PAC960P4-**
60-96V 600Arms
PAC945P3-**
60-96V 450Arms
PAC927P2-**
60-96V 270Arms
PAC914P1-**
60-96V 140Arms
PAC460P3-**
24-48V 600Arms
PAC445P2-**
24-48V 450Arms
PAC425P1-**
24-48V 250Arms
PMS Traction
PMS960T4-**
60-96V 600Arms
PMS945T3-**
60-96V 450Arms
PMS927T2-**
60-96V 270Arms
PMS914T1-**
60-96V 140Arms
PMS460T3-**
24-48V 600Arms
PMS445T2-**
24-48V 450Arms
PMS425T1-**
24-48V 250Arms
PMS Pump
PMS960P4-**
60-96V 600Arms
PMS945P3-**
60-96V 450Arms
PMS927P2-**
60-96V 270Arms
PMS914P1-**
60-96V 140Arms
PMS460P3-**
24-48V 600Arms
PMS445P2-**
24-48V 450Arms
PMS425P1-**
24-48V 250Arms
Example:
PAC960T4-01
Model Number Description
Motor Technology
PAC = 3 phase AC Induction
PMS = Permanent Magnet Synchronous
IPM = Interieur Permanent Magnet
Nominal Battery Voltage:
4 = 24/48V
9 = 60/96V
1 = 120V (future)
Maximum Current (Arms)
14 = 140 Arms
25 = 250 Arms
27 = 270 Arms
45 = 450 Arms
60 = 600 Arms
Frame Size
1 = Size 1 (160x200x72mm) (small)
2 = Size 2 (200x200x72mm) (medium)
3 = Size 3 (250x200x72mm) (medium+)
4 = Size 4 (320x200x72mm) (large)
Firmware Number
Configuration
T = Traction
P = Pump
E = Power steer
