DMC SuperSigma2 QRM User Manual

SuperSigma2 QRM PMS – V01.02.02 17-1-2020 Page 36 (58) ©2019 DMC GmbH Herten Germany
9.11 Menu 8 “BDI” Battery Discharge Indicator
The following menu includes the settings for the BDI algorithm.
Cal.
Ref.
Parameter
Calibrator
text
Min.
adjust
Max.
adjust
Step
size
Default
48V
Default
96V
1
Battery Current Limit Via Can type
BlcCanMsg
0
3
1
0
0
2
Nominal battery voltage
NomBatV
12. 0 V
Uabsmax
1 V
48 V
96 V
3
BDI reset level
BDIreset
12. 0 V
Uabsmax
0.1 V
50.2 V
100.3 V
4
BDI empty level
BDIempty
12. 0 V
Uabsmax
0.1 V
38.9 V
77.8 V
5
BDI warning level
BDIwarn
0 %
99 %
1 %
20 %
20 %
6
BDI cut out level
BDIcut
0 %
99 %
1 %
0 %
0 %
7
BDI speed limit (traction only)
BDIspeed
0.0 Hz
400.0 Hz
0.1 Hz
100.0 Hz
100.0 Hz
8
Drive Battery Current Limit (max. value)
IBattMax
0.0 A
700.0 A
0.1 A
700.0 A
700.0 A
9
Regen Battery Current Limit
IBattReg
0.0 A
700.0 A
0.1 A
700.0 A
700.0 A
For Battery Current Limits refer to Advanced Manual.
