9.9 Menu 6 “PMS Motor Advanced”
These parameters are reported for indication only and it is not possible to modify them without the assistance of DMC
engineers.
Cal.
Ref.
Parameter
Calibrator
text
Min.
Max.
Step
size
Default
1
Decouple Iq and Id controllers
Decouple
0
1
1
0
2
Enable software PWM algorithm delay compensation
PWMDelay
0
1
1
1
3
Limit torque controller during Voltage limiting
VoltSat
0
1
1
0
4
Speed Control Filter
SCFilter
0
1
1
1
5
Enable Voltage Limiter
VoltCtrl
0
1
1
0
6
Speed filter cut-off frequency
Fspdfilt
4 Hz
400 Hz
1 Hz
80 Hz
7
Percentage of correction for inductance value
DecoLeak
0 %
180 %
1 %
100 %
8
Back EMF correction factor
BEMFCorr
0 %
180 %
1 %
100 %
9
Speed estimator rate
Obs. Rate
2%
65%
1%
30%
10
Resistance compensation gain
R. Gain
70%
100%
1%
70%
11
Current compensation gain
Curr. Gain
0%
60%
1%
28%
12
Start Torque
StartTrq
0%
100%
1%
40%
13
Start Current
StartCur
0%
50%
1%
30%
14
Maximum radius voltage
Vmodmax
90%
102%
1%
102%
