SuperSigma2 QRM PMS – V01.02.02 17-1-2020 Page 48 (58) ©2019 DMC GmbH Herten Germany
10.2 PMS Motor sub error codes
Sub
Code
Description
0
No errors in the motor module.
1
The motor module could not be initialized.
2
An overcurrent is detected
3
Internal error refer to DMC
4
Wrong current: rated motor current is greater than max
5
Wrong poles number (is odd)
6
Wrong settings: rated motor voltage is too high in relation with the battery voltage capability. Check battery
voltage set in autotuning menu. Load defaults and reparmetrize
7
Internal error refer to DMC
8
Internal error refer to DMC
9
Sine signal is out of range: check connection and sensor
10
Cosine signal is out of range: check connection and sensor
11
No Hall sensor signals; check connection and sensor
12
Unable to perform recalculation: motor calculated maximum speed exceeds 500 Hz. Check motor
parameters.
13
Unable to perform recalculation: limit curves; check motor parameters (Ls, Ke, Fmax, Idemag) in auto tune
menu.
14
Unable to calculate controller gains: check motor parameters (Ls, Ke, Fmax, Idemag) and perform
recalculation or do autotuning again.
15
Internal error refer to DMC
