DMC SuperSigma2 QRM User Manual

SuperSigma2 QRM PMS – V01.02.02 17-1-2020 Page 8 (58) ©2019 DMC GmbH Herten Germany
4 TECHNICAL SPECIFICATIONS
4.1 Electrical
4.1.1 Voltage specifications:
Model
Nominal battery
voltage
Absolute operating voltage
range
Reduced braking
voltage levels (F4)
High Voltage cut out
level (F22)
PXX4xx-XX
24 V – 48 V
12.0 V – 72.5 V
60.0 V – 67.5 V
70 V
PXX9xx-XX
60 V – 120 V
12.0 V – 144.0 V
130.0 V – 138.5 V
140 V
Note: These voltage levels are used to set the voltage levels in the Limits menu.
4.1.2 Current specifications:
Model
Power
Current limit
(1 min)
Continuous current 1 hour
rating. Unit mounted on
an sufficient heat sink, at
20C ambient.
Controller frame size
PXX425XX
24/48V 250A
250Arms
130A
Size 1
PXX445XX
24/48V 450A
450Arms
250A
Size 2
PXX460XX
24/48V 600A
600Arms
330A
Size 3
PXX914XX
60/96V 140A
140Arms
75A
Size 1
PXX927XX
60/96V 270A
270Arms
140A
Size 2
PXX945XX
60/96V 450A
450Arms
230A
Size 3
PXX960XX
60/96V 600A
600Arms
300A
Size 4
Switching Frequency: Controller frequency is 8KHz (centre aligned PWM switching). Motor frequency 16KHz.
Electrical Isolation: Enclosure to any live part = 1KV. Controller internal insulation specified at >10MΩ @500V DC.
Reverse Battery Polarity: If line contactor installed according to the manual, yes
I/O details: See light wiring diagram.
4.2 Environmental
Impact Protection (IP): The enclosure is protected to IP65 (when AMP seal Connector fitted)
Vibration: 6G, 40-200Hz for 1 hour, in x, y and z planes.
Operating Temperature: -30
o
C to +40
o
C ambient around controller.
Storage Temperature: -40
o
C to +70
o
C.
Humidity: 95% maximum, non-condensing.
Humidity Resistance: Ingress protected, watertight AMP seal connector
Safety: Designed to the requirements of machine directive 2006/42/EC, safety of industrial trucks
EN1175-1:1998+A1:2010, EN13849-1, UL94.
The vehicle manufacturer is responsible for the compliance of the complete system with the
appropriate regulations.
EMC: EN 12895 (2015), (Immunity tested at 30V/M)
EN 61000-6-3 (2007) +A1 (2011) + AC (2005) (Residential Emissions, Class B)
EN 61000-6-2 (2005) + AC (2005) (Industrial Immunity)
The machine manufacturer is responsible for the compliance of the complete system with the
appropriate regulations.
