SuperSigma2 QRM PMS – V01.02.02 17-1-2020 Page 25 (58) ©2019 DMC GmbH Herten Germany
Cal.
Ref.
Parameter
Calibrator
text
Options (defaults are in bold)
Range
17*
Accelerator supply wire off
detection
SplyWrOf
0 = No supply wire off detection
1 = 0V wire off detection enabled
2 = 5V wire off detection enabled
3 = Both 0V and 5V wire off detection
0 – 3
18
Standby timer
StdByDly
Adjustable from 0 to 10 Minutes.
Default is 0 (0=Off)
0 - 10
19
Drive output 2
Configuration
Drv2Cfg
0 = EM brake function
1 = motor temperature cooling enabled
2 = controller temperature cooling enabled
3 = both motor and controller temperature cooling
enabled
0 – 3
20
Drive output 3
Configuration
Drv3Cfg
0 = Power Steer function
1 = motor temperature cooling enabled
2 = controller temperature cooling enabled
3 = both motor and controller temperature cooling
enabled
0 – 3
21
Drive Output Motor Temp
TH
MotTmpTh
Adjustable from 10 to 127 °C. Default is 70 °C
10 – 127
°C
22
Drive Output Controller
Temp TH
CtrTmpTh
Adjustable from 10 to 100 °C. Default is 45 °C
10 – 100
°C
23
Line Contactor pull-in level
LCPlInLv
Adjustable from 50% to 100% Ubatt.to limit inrush
current. Default is 90%
50-100%
24
Line Contactor pull-in time
out
LCPlInTO
Line Contactor pull in time out. Default is 10sec.
0-12 sec
25
Drive torque during
braking
DTrq@Brk
0 = no drive torque allowed during brake
1 = drive torque is allowed during brake
0 - 1
26
Line Contactor Coil pull-in
Voltage
LCPlInVl
Adjustable from7% to 100% Ubatt Default is 100%
7-100%
27
Line Contactor Coil Holding
voltage
LCHoldVl
Adjustable from 7% to 100% Ubatt Default is 100%
7-100%
28
Digital output 2 pull-in
voltage
DO2PlInV
Adjustable from 7% to 100% Ubatt Default is 100%
7-100%
29
Digital output 2 hold
voltage
DO2HoldV
Adjustable from 7% to 100% Ubatt Default is 100%
7-100%
30
Digital output 3 pull-in
voltage
DO3PlInV
Adjustable from 7% to 100% Ubatt Default is 100%
7-100%
31
Digital output 3 hold
voltage
DO3HoldV
Adjustable from 7% to 100% Ubatt Default is 100%
7-100%
32
n/a
n/a
33
Calibration Data Options
CalValue
Not active
---
34*
Loading Default
LoadDefs
0 = Don't load defaults
1 = Load defaults
0 – 1
(*) Recycle the key switch to make changes active. (Also indicated on calibrator ‘key’)
