DMC SuperSigma2 QRM User Manual

SuperSigma2 QRM PMS – V01.02.02 17-1-2020 Page 44 (58) ©2019 DMC GmbH Herten Germany
… Errors continue from previous page
Base
fault
Code
Description
Sub
fault
code
Description
7
Adjustment out of range
16
Shared Line contactor HMI “master node” (“CAN node”) is
higher/equal than last node (“LstNode”). This happens in
the controller with the setting “ShareLC”=2 if “CAN
node”>= “LstNode”, that is a non-sense.
Solution: check node assignment, and make sure “CAN
node” < “LstNode
17
Shared Line contactor HMI “slave node” “CAN node”) is
lower/equal than Shared Line contactor HMI “master”
node (defined in “LstNode”). This happens in the
controller with the setting “ShareLC”=3 if “CAN node”<=
“LstNode”, that is a non-sense. Solution: check node
assignment, and make sure “CAN node” > “LstNode”
18
Safe Stop 1 and CAN node ID Via digital Inputs not
compatible
19
PC interface request controller to stop pulsing
< 999
First digit: menu number
Last 2 digits: adjustment number within menu
999
Power PCB doesn't match firmware
8
Default adjustments used
-
Drive error faults - Commences graceful neutral brake – Requires a neutral recycle action to reset fault
9
Memory chip fault
> 0
Contact DMC
10
Both forward and reverse inputs active
-
Both direction switches are active at the same time.
Notice that this fault is detected with 1s delay.
11
Ride-on: Seat switch not closed or timed
out
Walkie: Tiller switch not closed
-
12
Power up sequence fault
1
Traction: FS1 switch active at power up
2
Traction: Forward switch active at power up
3
Traction: Reverse switch active at power up
4
Pump: speed 1 or pump pot active at power up
5
Pump: speed 2 active at power up
6
Pump: speed 3 active at power up
7
Pump: speed 4 active at power up
8
Pump: speed 5 active at power up
9
Inching: Forward switch active at power up
10
Inching: Reverse switch active at power up
11
Inhibit direction change fault
12
CAN HMI Safety Stop 1 switch inactive fault
13
Accelerator more than 50% at power up
1
Normal accelerator type high at power up
2
Wig-wag high at power up
14
Inching sequence faults
1
Forward switch active when inching
2
Reverse switch active when inching
3
FS1 switch active when inching
4
Seat switch active when inching
5
Foot Brake switch active when inching
6
Hand Brake active when inching
7
Both inching buttons active when inching
8
Inching buttons active when normal drive
Belly switch active
-
Errors continue at next page…
