N.
Fault
Type
Description
Remedy
55
Fault SCS
Safety Circuit Shunt.
Function enabled by “Shaft Monitor”
parameter. See annex X
Cod 2: Second contact door A
shunted.
Cod 4: Floor door contacts door A
Shunted (SE4 input)
Cod 6: Car door contacts door A
Shunted (SE6 input)
Cod 12: Second contact door B
shunted.
Cod 14: Floor door contacts door B
Shunted (SE4 input)
Cod 16: Car door contacts door B
Shunted (SE6 input)
Cod 100: No SE6 input during bypass
(ISO Circuit)
Check circuit according cod’s info.
Reset SCS parameter in the menu Faults
(§ 5.3).
Cod 2: Check second contact door A
(FFA input for door operator, CEA
input for manual cabine door).
Cod 4: Check Floor door’s safety
contacts door A (SE4 input)
Cod 6: Check Car door’s safety contacts
door A (SE6 input)
Cod 12: Check second contact door B
(FFB input for door operator, CEB
input for manual cabine door).
Cod 14: Check Floor door’s safety
contacts door B (SE4 input)
Cod 16: Check Car door’s safety
contacts door B (SE6 input)
Cod 100: Check doors bypass Circuit
(SE3-SC5).
56
Fault UAS
Unintended Shaft Access
Function enabled by “Shaft Monitor”
parameter.
Must be used BDU with additional
door input (could be NO or NC).
System detect a manually floor door
opening monitoring the auxiliary door
input.
Cod 1: One Floor door manually open
(with no open door command).
Cod 2: More than one Floor door
manually open (at different floors)
Reset UAS in the menu Faults (§ 5.3).
57
Bypass door
Only for EN 81-20.
Bypass active on door safety
contacts.
(Moving enabled only in inspection)
Check also SM1 module monitor
Cod 1: Bypass Car active
Cod 2: Bypass Pre-Locks active
Cod 3: Bypass Locks active
Cod 100: Module SM1 locked
Cod 100: Module SM1 is checked if only
PME selector is active and no STOPS
nor direction button pressed: in that
condition module SM1 must be not
enabled and SE3 input should be open.
58
Overspeed
Only for Encoder positioning system.
In inspection or Temporary mode
Lift’s speed is more than 0,63 m/s
Check encoder parameters or inspection
speed in positioning menu.
59
Fault SHI
Only for 81-21 Pre-triggered device
Cod 0: Wrong feedback when pre-
triggered device is not energized
Cod 255: Wrong feedback when pre-
triggered device is energized
Manual protection:
Cod 101: Monitor Relay RMPP
(contact doesn’t open)
Cod 102: Monitor Relay RMPP
(contact doesn’t close)
Check Pre-Triggered Device (or relay
RMPP)
