60
Fault ELGO
ELGO Fault.
Cod 0: Upper Limit switch
Cod 1: Lower Limit switch
Cod 4: Pre-triggered Stopping system
Top
Cod 5: Pre-triggered Stopping system
Bottom
Cod 8: Normal mode overspeed (pre
tripping)
Cod 9: Normal mode overspeed (final
tripping)
Cod 11: Inspection mode overspeed
(final tripping)
Cod 13: Teach mode overspeed (final
tripping)
Cod 14: Normal mode overspeed
(leveling)
Cod 15: Normal mode overspeed (re-
leveling)
Cod 16: Deceleration control (ETSL)
Cod 24: Unintended car movement
Cod 100: ELGO not in operative
mode
Cod 102: ELGO’s Input EN81-21 in
Manual Teach mode
Cod 103: ELGO’s eSGC_POW
missing in Manual Teach mode
Cod 104: Restarting error in Manual
Teach mode
Cod 121: Input ELGO 81.21 not
matching (all time OFF)
Cod 122: Inputs ELGO UP/DOWN
(not active)
Cod 123: Input ELGO UP not
matching
Cod 124: Input ELGO DOWN not
matching
Cod 125: Inputs ELGO UP/DOWN not
matching (all time ON)
Cod 200: Communication time out
Cod 254: Self test ELGO Error Level
4
Cod 255: Magnetic Band missing
Check ELGO configuration data.
Check ELGO wiring
Make a Fault reset to remove the fault.
Cod 0: Move car down (under the limit
switch position) and make a specific
Reset SE3 fault (§5.3).
Cod 1: Move car up (over the limit switch
position) and make a specific Reset SE3
fault (§5.3).
Cod 4: only information, Inspection upper
limit switch.
Cod 5: only information, Inspection lower
limit switch.
Cod 8/9: Make a Fault reset. Check Lift
speed and ELGO’s Configuration.
Cod 11: Make a Fault reset. Check Lift
speed and ELGO’s Configuration.
Cod 13: Make a Fault reset. Reduce the
lift speed in Teach mode (max 0,6 m/s).
Cod 14: Make a Fault reset. Reduce the
lift speed during the stop at floor (max
0,8 m/s).
Cod 15: Make a Fault reset. Reduce the
lift speed in re-levelling (max 0,3 m/s).
Cod 16: Fault is automatically removed
when lift is standstill. Increase
Deceleration distances (R1D/R1S).
Cod 20: In Inspection, on the lower limit
switch a down movement checked with a
UP command. Check rollback effect.
Cod 21: In Inspection, on the higer limit
switch an up movement checked with a
DOWN command. Check rollback effect.
Cod 100: Need a Manual Teach
procedure
Cod 102: Check wiring of ZP2 signal in
the controller
Cod 103: Check wiring of cable eSGC
(power missing)
Cod 104: Need Chenge device
Cod 121: Check wiring of ELGO and
TOC’s signal output. Error means a
mismatch between command from
controller and ELGO’s diagnostic.
Cod 121125: Check wiring of ELGO
and TOC’s signals output. Errors means
a mismatch between commands from
controller and ELGO’s diagnostic.
