After the Calibration procedure check the status of parameter “Integrated Load Weighing” in menu
<Special Features>.
Calibration Procedure Must be repeated in case of any changing into the cabin (panels,
flooring, COP changing etc.) or on the counterweight (lift balancing).
Test 23: Measure of the stopping space and time in UP direction at rated speed with Safety Gear
(only OSG A3)
Before starting the test, move the empty car to the ground floor.
During the test, the car will move upwards and after reaching the nominal speed, as soon the car
reach the first floor (AGH for two stops installations) the controller removes the OSG’s A3 pin
causing the stop of the lift. After the car has been stopped, the distance covered from the second
last floor and the stopping level and the stopping time are shown. To control only the safety gear as
a locking system, when starting the lift keep the brakes energized by manually operating the
contactors.
Test 24: Measure of the stopping space and time in DOWN direction at rated speed with Safety Gear
(only OSG A3)
Before starting the test, move the full loaded car to the top floor.
During the test, the car will move downwards and after reaching the nominal speed, as soon the car
reach the first floor (AGB for two stops installations) the controller removes the OSG’s A3 pin
causing the stop of the lift. After the car has been stopped, the distance covered from the second
last floor and the stopping level and the stopping time are shown. To control only the safety gear as
a locking system, when starting the lift keep the brakes energized by manually operating the
contactors.
Test 25 Test 26: Not Used
Test 27: Check of landing doors locked from the cabine
It is useful in order to check that landing doors are locked. It is executed with a special key in the car to
check landing doors at penthouse floor. Test will move the cabine 300 mm over the floor level (under floor
level at the top floor) and opens the cabine’s door. During the test an intermittent acoustic signal sounds in
the cabine.
Test finish after a maximum of 60 seconds or when a second activation on the special key is given.
Technician can moves the lift by a COP call.
Test can be also executed by the Playpad at each floor.
After the test lift come back in service.
