ParaMon-Pro X instruction manual DOC.60391-01/21
R. Fastening stop error
Unless ‘Torque UP’ is detected during ‘Trigger ON – OFF’, this feature decides if ‘Fastening stop error’ alarm
should go off.
If ‘ON’, operating procedures are as follows:
1.Press the trigger for a while and release to start the tool.
2.If torque is increased after the process 1 above, ‘Fastening stop error’ does not occur.
3.Unless torque is increased after the process 1 above, check if the tool rotated up to the number of turns
preset in ‘Judged fasten min. turns’.
4.If greater than ‘Judged fasten min. turns’, the ‘Fastening stop error’ alarm goes off.
5.If rotated by less than ‘Judged fasten min. turns’, the fastening stop error does not occur.
S. Reverse lock
Decides if reverse rotation should be allowed.
If ON, it rotates in a forward direction only regardless of forward/reverse switch settings.
T. LCD button lock
Able to restrict the function keys and use them for three purposes:
Permits the use of all keys without any functional restrictions
F1 is restricted.
The restriction on F1 permits changes in preset No.
However, changes in preset torque and speed are not allowed.
Restricts the use of all keys except for alarm reset.
Unable to modify all settings such as preset No., torque and speed.
Used in situations which are strictly controlled by an external controller such as
ParaMon-Pro X.
U. Auto data output
Not available when the BM is used together with ParaMon-Pro X.
Automatically turned off if the BM is connected to ParaMon-Pro X.
If set to ‘ON’ by force, communication between the BM and ParaMon-Pro X become abnormal.
Ensure to keep it OFF all the time when ParaMon-Pro X is used.
V. Torque unit
Sets a torque unit.
The tool is automatically reset when torque unit is being set.
