Service Manual
Ophthalmic Surgical System
Chapter 2 - Maintenance instructions
28 - Version date: Nov. 01, 2013 - N° doc.: 30204400-B
13. Carefully remove the laser fiber through
the EVA.
14. Remove the CAN cable.
15. Unscrew the screw of the laser module
support.
Support the laser module during
unscrewing.
16. Carefully move the laser module back-
wards.
Be careful ! The laser fiber is
still connected.
