REAR LOADERS
CHASSIS INTERFACE RELAY BANK
4.6.1
NEUTRAL
Printed in U.S.A.
COPYRIGHT 2004, H.E.I.L.
ISSUED APRIL 2004
CHASSIS INTERFACE RELAY BANK
REVERSE
TAIL
THROTTLE
LIMIT
CLEAR
L. TURN
R. TURN
STOP
NEUTRAL
The chassis interface relays are
used in all rear loaders to carry
the load current for lights,
throttle stop, throttle limit,
neutral, etc. The number o
relays used may vary depending
on chassis and unit set up.
