Dover HEIL DuraPack 5000 - Location of Oil Tank

5.7
LOCATION OF HYDRAULIC OIL TANK with IN-TANK OIL FILTER
In most cases, the hydraulic oil tank with in tank filter is located on the left (streetside) of the unit and
mounted to the chassis. In some optional cases, the tank in mounted above the front head of the
body.
IN-TANK
O
IL FILTER
HYDRAULIC OIL
TANK
Printed in U.S.A.
©COPYRIGHT 2002, H.E.I.L.
ISSUED APRIL 2002
